Mini Plastic Extrusion Machine , Polypropylene Extrusion Machine Single Screw

Mini Plastic Extrusion Machine , Polypropylene Extrusion Machine Single Screw
Mini Plastic Extrusion Machine , Polypropylene Extrusion Machine Single Screw Mini Plastic Extrusion Machine , Polypropylene Extrusion Machine Single Screw

Large Image :  Mini Plastic Extrusion Machine , Polypropylene Extrusion Machine Single Screw

Product Details:
Place of Origin: China
Brand Name: ZHMC Machiney
Certification: CE
Model Number: SJ 45 / 75
Payment & Shipping Terms:
Minimum Order Quantity: Two units
Price: Negotiable
Packaging Details: Wooden Package
Delivery Time: 30 days
Payment Terms: T/T
Supply Ability: 20+Units+Per Month

Mini Plastic Extrusion Machine , Polypropylene Extrusion Machine Single Screw

Description
Application: Sheet, Pipe, Profile, Plate, Filament Voltage: 380V 415V
Screw: Single Screw Weight: 200kg
Color: Customized Warranty: 12 Month
High Light:

plastic extrusion equipment

,

plastic moulding machine

SJ 25 SJ 45 Mini Extruder small polypropylene extrusion machine with single screw




SJ 25 SJ 45 Mini Extruder Product Description



1 .  SJ-45 small single screw plastic extruder can be used in pipe production line, sheet/board

production line and filament production line. It is widely used in different areas.

2 .  This machine can process all kinds of plastic materials such as soft/hard propene polymer(PP) and polystyrene(PE) coordinated with the appropriate auxiliary machine.

3 .  The SJ25 Mini Plastic Extruder is mainly used for experiment, that used for testing and extruding thermo-plastic such as soft hard polyvinyl chloride (PVC) and polystyrene(PE) coordinated with the appropriate auxiliary machine,(including the die).

4 .  This Mini Plastic Extruder is advanced in design, good in plasticization and low in energy consumption. The extruder is characterized by low noise, stable working, big bearing capacity and long service life.





Feature



1 .  Small size which can be moved easily.

2 .  Low energy consumption

3 .  This machine is mainly for small factory

4 .  Mini exruder is an inportant auxiliary for many lines





Main Technical Standards



Model No. SJ25
Screw Diameter 25 mm
Ratio of L/D 30:1
​Screw Material 38CrMoAlA
Hardness of Screw HV900-1000
HV900-1000 0.4-0.7 mm
Screw Straightness <0.015 mm
​Main Motor Power 3KW
3KW Casting Aluminum Heater
Heating Zones 3Periods(Screw Barrel 2periods,Head Piece 1 Periods)
Heating Power 1.5KW*3=4.5KW
Screw Maximum Rotating Speed 60 rpm
Maximum Capacity 3-5Kg/h



Model SJ-45
SJ-45 45
Main motor power(kw) 7.5
Barrel heating power(kw) 6
Screw speed(r/min) 120
Plasticization capability(kg/h) 50
L/D 25:1
Central height(mm) 1000





Main Parts



Name Manufacturer
Main Motor AC Motor
Screw and Barrel Famous Screw
Electrical System Siemens Contactor / RKC Temperature Control Meter
Converter ABB Frequency Converter




Our Services



1 .  Hose/Cover color: many kinds of colors can be customized.

2 .  Stamp: Specification or logo stamp can be printed on the hose.

3 .  Length:30-100M/roll at customer's option

4 .  Other wall thicknesses and weights for each meter can be customized.

5 .  Customized card board printing.

6 .  Accessory Available:Camlock Hose Coupling,Storz,Pin lug,Jorn Morris Hose Coupling, American,German or British Type Hose Clamp

7 .  Package: According to the company standard or can be customized.

8 .  Guarantee delivery date.





Product Display

Mini Plastic Extrusion Machine , Polypropylene Extrusion Machine Single Screw 0
