Large Diameter Pipe Coiler Machine , High Speed HDPE Pipe Coiler Durable

Large Diameter Pipe Coiler Machine , High Speed HDPE Pipe Coiler Durable
Large Diameter Pipe Coiler Machine , High Speed HDPE Pipe Coiler Durable Large Diameter Pipe Coiler Machine , High Speed HDPE Pipe Coiler Durable

Large Image :  Large Diameter Pipe Coiler Machine , High Speed HDPE Pipe Coiler Durable

Product Details:
Place of Origin: China
Brand Name: ZHMC Machiney
Certification: CE
Model Number: Plastic coiling machine
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Wooden package
Delivery Time: 30 days
Payment Terms: T/T
Supply Ability: 15 sets per month

Large Diameter Pipe Coiler Machine , High Speed HDPE Pipe Coiler Durable

Description
Specification: 50mm-160mm Pipe Size: 20-75mm
Automation: Automatic Diameter: 16mm-63mm
Product Type: PE Water-supply Pipes Speed: 0-40m/Minute
High Light:

tube coiling machine

,

plastic pipe coiler

Automatic Winding Machine for HDPE Pipe Coiler 20-75mm large diameter plastic pipe


Automatic Winding Machine Feature


1. It adopts automatically winding. Adjusting winding speed and winding method.
2. It has two disk for continuous winding. It adopts air-operated method.
3. The wheel rib of the winding up wheel adopts air-operated opening and closing.
4. It is equiped with a ray creel stand to automatically wind displacement.
5. It reaches winding up orderly, automatically.
6. Its appearance is beautiful and its operation is convenient.

Description

1. Coiler is the part of pipe extrusion lines. It is composed by Drive unit, Guide system and Control parts.
2. It usually adopted by HDPE pipe extrusion line and Single wall corrugated pipe production line.
3. Coiler makes the pipe Storage and transportation more convenient.
4. Also when the pipe packed in a roll will be much better for a pipe construction. Less pipe joints bring better pipe system.

Specification

As a professional manufacturer, We have full sincerity to look for new customers, good distributor, wholesaler or agent in different countries to enlarge business share together.

Model SPS280 SPS400 SPS700
Disk Min Size (mm) 280 400 700
Disk Max Size (mm) 700 1200 1800
Winding width (mm) 220 300 500
Maximum rolling pipe (mm) 20 50 75



Model 1200 twin-plate pipe 1600 twin-plate pipe 3000 single-plate pipe
Inner diameter 500-1000mm 550-1000mm 1000-3000mm
Winding speed 0.5-30m/min 0.5-30m/min 0.5-15m/min
Winding width 300-500mm 300-500mm 200-500mm
Winding pipe spec 16-32mm 16-63mm 63-110mm
Air pressure 0.6mpa 0.6mpa 0.6mpa
Moment motor power 10N. M 10N. M& 16N. M 30N. M
Dimension 2700× 1700× 1800 3000× 2800× 2000 3500× 2000× 3500
Weight 1000kg 1500kg 3000kg



Model SPS400 SPS1200 DP1800
Coil pipe specification Φ16-40 mm Φ 20-63mm Φ50-125mm
Coil inner diameter Φ400 Φ700 Φ1200
Coil speed 0.5-15m/min 0.8-8/min 3-12m/min
Coil width 300mm 500mm 660mm
Air pressure 0.6Mpa



Detailed Picture

Large Diameter Pipe Coiler Machine , High Speed HDPE Pipe Coiler Durable 0
