High Capacity Plastic Extrusion Equipment For Roof Skylight Hollow Polycarbonate Sheet

High Capacity Plastic Extrusion Equipment For Roof Skylight Hollow Polycarbonate Sheet
High Capacity Plastic Extrusion Equipment For Roof Skylight Hollow Polycarbonate Sheet High Capacity Plastic Extrusion Equipment For Roof Skylight Hollow Polycarbonate Sheet

Large Image :  High Capacity Plastic Extrusion Equipment For Roof Skylight Hollow Polycarbonate Sheet

Product Details:
Place of Origin: China
Brand Name: ZHMC Machiney
Certification: CE
Model Number: SJ 120 / 90 / 75
Payment & Shipping Terms:
Minimum Order Quantity: One unit
Price: Negotiable
Packaging Details: Wooden Package
Delivery Time: 30 days
Payment Terms: T/T
Supply Ability: 20+Units+Per Month

High Capacity Plastic Extrusion Equipment For Roof Skylight Hollow Polycarbonate Sheet

Description
Application: Polycarbonate Panel Color: Blue,lake Blue,orange, Green,opal,brown
Screw: Three Screw Item: Polycarbonate Four Layer PC Sheet
Product: Polyethylene Pipe Certification: CE
High Light:

plastic extrusion equipment

,

plastic moulding machine

Roof skylight Three layers hollow polycarbonate sheet extruded sheet extruder plastic machine





Three Layers Hollow Polycarbonate Sheet Extruder Description



1 .  PC four layer sheet is high performance engineering plastics-polycarbonate (PC) resin processing,

is high-tech,comprehensive performance is very excellent,energy saving and environment protection.

2 .  The PC sheet is the widely used in plastic building materials and other building decoration materials

(such as glass,organic glass,etc)can not math the advantages, be known as”no broken glass”





Features



1 . Light transmission: up to 92%

2 . Impact resistant:80 times that of glass, 15 times that of acrylic sheet

3 . Temperature range:-40-120 Celsius degree

4 . Light weight: 1/12 of the weight of glass at same thickness

5 . UV protected

6 . Fire retardance: rated Class B1

7 . Sound & Heat insulation





Triple Layer Three Extruders Product Description



1. Specified screw design for better material plasticizing & mixing effect so as to guarantee the good quality pipe manufacturing.

2. Filter type die head structure for material further plasticizing, manufacturing pipe of better mechanical properties.

3. Centralized vacuum water tank design, optimized solid cone spray design, efficient energy saving, cooling calibrators with water ring speed up line speed of 30-40%.

4. Automatic control system of water level and water temperature to avert of PPR pipe brittle cracking during the application.

5. Full-automation no dust cutting unit, featured with speedy & smoothly cutting, no dust produced. Accurate fixed-length cutting design, ensure strict synchronization follow-up and flexible moving speed.



Main Technical Parameters



Model L/D Capacity (kg/h) Screw Speed (rpm) Power (kw) Center Height (mm)
SJ-25 25-30/1 1-5 120 1.1-2.2 1000
SJ-45 25-38/1 20-80 120 7.5-22 1000
SJ-65 25-38/1 60-200 120 37-55 1000
SJ-75 25-38/1 120-400 120 55-110 1000
SJ-90 25-38/1 250-600 120 55-180 1200
SJ-120 25-38/1 600-1000 90 90-315 1200
SJ-150 25-38/1 1000-1300 90 110-380 1200




Pipe Application



NO. Diameter(mm) Die head Layer Length(mm)
1 16-32 Single/Double Outlet One/Three 48
2 16-63 Single/Double Outlet One/Three 50
3 20-110 Single Outlet One/Three 52
4 40-160 Single Outlet One/Three 54
5 75-250 Single Outlet One/Three 56




Product Display

High Capacity Plastic Extrusion Equipment For Roof Skylight Hollow Polycarbonate Sheet 0
